Stainless steel heavy duty clamps type 402-6.6 (for all type of pipes)

Stainless steel heavy duty clamps type 402-6.6 (for all type of pipes)

Type: 310ss General Information:

  • two screw clamp
  • for horizontal and vertical pipe fixing
  • CO2 welded nut. Upon request also available with a different size nut.
  • material: stainless steel AISI 316L (A4). Upon request also available stainless steel AISI 304 (A2)

  • Description
  • Product Overview

Description

General Information:

  • two screw clamp
  • for horizontal and vertical pipe fixing
  • CO2 welded nut. Upon request also available with a different size nut.
  • material: stainless steel AISI 316L (A4). Upon request also available stainless steel AISI 304 (A2)

Technical information:

  • side locking screws (S1) DIN 7985
  • max. allowed load, from dimension 19-22 to 62-66 (N) 1.880, from 72-80 to 99-103 (N) 3.530
  • max. allowed load is calculated for static load only in (N) Newton, 1 (N) = 0,102 kg / 1 kg = 9,8 (N)
